Show warchip class:
Freedom

SPECS for Freedom
Type warshipFFL - Littoral Combat Ship
Displacement3.500 tons
Crew115 complement
Length115,00 meters
Beam17,50 meters
Draught3,90 meters
Speed47,0 knots
Range6.500 Km
Propulsion2 X CODAG resulting in 50.000HP
Planes0
Helicopters3
Weapons
1Helicopter Sikorsky MH-60R Seahawk (AN-ASW; range:834 km; speed:270 km/h;)
2Helicopter (UAV) Northrop Grumman MQ-8 Fire Scout ( range:400 km; speed:213 km/h;)
21Missile RIM-116 Rolling Airframe Missile (AA-AM; range:9 km; speed:2450 km/h;)
1Gun Bofors 57 mm (AA-AM-AN; range:8,5 km; speed:4000 km/h; caliber:57 mm;)
24Missile AGM-114 Hellfire (AN; range:8 km; speed:1591 km/h; caliber:178 mm;)
2Gun 30mm DS30M Mark 2 Automated Small Calibre Gun (Bushmaster Mk44) (AA-AM; range:2 km; speed:4000 km/h; caliber:30 mm;)
4Gun Rogue Remotely Operated Guns (AA-AN; range:1 km; speed:4000 km/h; caliber:12,7 mm;)

IN SERVICE: 5,00
Country Pennant Name In service Photo
USA LCS-1 USS Freedom 2008
USA LCS-3 USS Fort Worth 2012
USA LCS-5 USS Milwaukee 2015
USA LCS-7 USS Detroit 2016
USA LCS-9 USS Little Rock 2017
